EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 57 / 82
4 Antenna Interfaces
EG060V-EA provides a main antenna interface and an Rx-diversity antenna interface which is used to
resist the fall of signals caused by high speed movement and multipath effect. The impedance of antenna
ports is 50 Ω.
4.1. Main/Rx-diversity Antenna Interface
4.1.1. Pin Definition
The pin definition of main antenna and Rx-diversity antenna interfaces are shown as below.
Table 27: Pin Definition of RF Antenna
4.1.2. Operating Frequency
Table 28: EG060V-EA Operating Frequencies
Pin Name
Pin No.
I/O
Description
Comment
ANT_MAIN
107
IO
Main antenna interface
50 Ω impedance
ANT_DRX
127
AI
Diversity antenna interface
50 Ω impedance
3GPP Band
Transmit
Receive
Unit
WCDMA B1
1920–1980
2110–2170
MHz
WCDMA B5
824–849
869–894
MHz
WCDMA B8
880–915
925–960
MHz
LTE B1
1920–1980
2110–2170
MHz
LTE B3
1710–1785
1805–1880
MHz
LTE B5
824–849
869–894
MHz
