Quectel LTE-A Series User Manual

LTE-A Module Series
EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 64 / 82
5.2. Power Supply Ratings
Table 31: Module Power Supply Ratings
5.3. Operation and Storage Temperatures
The operation and storage temperatures are listed in the following table.
Table 32: Operation and Storage Temperatures
1.
1)
Within operating temperature range, the module is 3GPP compliant.
2.
2)
Within extended temperature range, the module keeps the ability to establish and maintain a voice,
SMS, data transmission, emergency call, etc. There won’t be unrecoverable malfunctions. Nor will
there be effects on the radio spectrum or harm to radio networks. Only one or more parameters like
P
out
might reduce in the value and exceed the specified tolerances. When the temperature returns to
normal operating temperature levels, the module will meet 3GPP specifications again.
3. It is not recommended to use the module without adopting a heat dissipation component. Tests are
conducted at all temperature levels with heat sinks and rubber pads applied.
Item
Description
Conditions
Min.
Typ.
Max.
Unit
VBAT
VBAT_BB and
VBAT_RF
The actual input voltages must
stay between the minimum
and maximum values.
3.3
3.8
4.3
V
USB_VBUS
USB connection
detect
3.0
5.0
5.25
V
Item
Min.
Typ.
Max.
Unit
Operating Temperature Range
1)
-20
+25
+55
ºC
Extended Operation Range
2)
-25
+60
ºC
Storage Temperature Range
-40
+90
ºC
NOTES
