LTE-A Module Series
EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 16 / 82
3 Application Interfaces
3.1. General Description
EG060V-EA is equipped with 299 LGA pins that can be connected to a cellular application platform. The
following chapters describe the interfaces listed below.
⚫ Power supply
⚫ (U)SIM interface
⚫ USB interface
⚫ UART interfaces
⚫ PCM and I2C interfaces
⚫ ADC interfaces
⚫ Network indication Interfaces
⚫ Module status indication Interface
⚫ RI behaviors
⚫ PCIe interface*
⚫ WLAN control interface*
⚫ SD card interface*
⚫ SPI interface
⚫ USB_BOOT interface
⚫
