Quectel LTE-A Series User Manual

LTE-A Module Series
EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 26 / 82
1.
1)
The current consumption is tested in 3G/4G instead of 2G environment.
2.
2)
The SPI interface only supports master mode.
3. “*” means under development.
3.4. Operating Modes
The table below briefly summarizes the module’s operating modes referred to in the following chapters.
Table 5: Overview of Operating Modes
W_DISABLE#
151
DI
Airplane mode
control
V
IL
min = -0.3 V
V
IL
max = 0.6 V
V
IH
min = 1.2 V
V
IH
max = 2.0 V
1.8 V power domain.
Pulled up by default.
Bringing it LOW sets
the module into
airplane mode.
If unused, keep it
open.
USB_BOOT
140
DI
Force the module
into emergency
download mode.
V
IL
min = -0.3 V
V
IL
max = 0.6 V
V
IH
min = 1.2 V
V
IH
max = 2.0 V
1.8 V power domain.
If unused, keep it
open.
SLEEP_IND
144
DO
Indicate the
module's sleep
mode
V
OL
max = 0.45 V
V
OH
min = 1.35 V
1.8 V power domain.
If unused, keep it
open.
RESERVED Pins
Pin Name
Pin No.
I/O
Description
DC Characteristics
Comment
RESERVED
3, 4, 6, 7, 8, 9, 11, 12, 14, 15, 18–23, 37, 38, 40, 41,71–74,
77–80, 91, 95, 101, 113, 115, 119, 134, 135, 152, 159, 161,
162,172, 176, 192–195, 197–201,209–213 18–23,
37,38,40,41, 71–74,77–80,192–195, 197–201, 209–213
Keep these pins
disconnected.
Mode
Details
Normal
Operation
Idle
The module has registered on network and is ready to send and
receive data, its software being active.
Talk/Data
The module is connected to network, its power consumption decided
by network setting and data transfer rate.
NOTES
