Quectel LTE-A Series User Manual

LTE-A Module Series
EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 65 / 82
5.4. Current Consumption
Table 33: Module Current Consumption
Description
Conditions
Typ.
Unit
OFF state
Power down
10
µA
Sleep state
AT+CFUN=0 (USB disconnected)
2.218
mA
WCDMA PF = 64 (USB disconnected)
4.143
mA
WCDMA PF = 128 (USB disconnected)
3.295
mA
WCDMA PF = 512 (USB disconnected)
2.607
mA
LTE-FDD PF = 32 (USB disconnected)
7.171
mA
LTE-FDD PF = 64 (USB disconnected)
4.854
mA
LTE-FDD PF = 128 (USB disconnected)
3.643
mA
LTE-TDD PF = 32 (USB disconnected)
7.781
mA
LTE-TDD PF = 64 (USB disconnected)
4.984
mA
LTE-TDD PF = 128 (USB disconnected)
3.539
mA
Idle state
WCDMA PF = 64 (USB disconnected)
29.29
mA
WCDMA PF = 64 (USB connected)
42.99
mA
LTE-FDD PF = 64 (USB disconnected)
29.87
mA
LTE-FDD PF = 64 (USB connected)
43.61
mA
LTE-TDD PF = 64 (USB disconnected)
29.89
mA
LTE-TDD PF = 64 (USB connected)
43.89
mA
WCDMA data
transfer
WCDMA B1 HSDPA CH10700 @ 22.78 dBm
571
mA
WCDMA B1 HSUPA CH10700 @ 20.40 dBm
484
mA
WCDMA B5 HSDPA CH4407 @ 22.64 dBm
496
mA
WCDMA B5 HSUPA CH4407 @ 20.10 dBm
415
mA
WCDMA B8 HSDPA CH3012 @ 22.80 dBm
544
mA
