5.6. RF Receiving Sensitivity
The following tables show conducted RF receiving sensitivity of the module.
Table 35: Conducted RF Receiving Sensitivity
1)
SIMO is a smart antenna technology that uses a single antenna at the transmitter side and two
antennas at the receiver side to improve Rx performance.
5.7. Electrostatic Discharge
The module is not protected against electrostatics discharge (ESD) in general. Consequently, it is subject
to ESD handling precautions that typically apply to ESD sensitive components. Proper ESD handling and
packaging procedures must be applied throughout the processing, handling and operation of any
Frequency
Primary
Diversity
SIMO
1)
3GPP (SIMO)
WCDMA B1
-109.5
/
/
-106.7
WCDMA B5
-109.5
/
/
-104.7
WCDMA B8
-109.5
/
/
-103.7
LTE-FDD B1 (10 MHz)
-97
-97
-100.5
-96.3
LTE-FDD B3 (10 MHz)
-97
-96.5
-100.5
-93.3
LTE-FDD B5 (10 MHz)
-97.5
-98
-101
-94.3
LTE-FDD B7 (10 MHz)
-95
-95.5
-97.5
-94.3
LTE-FDD B8 (10 MHz)
-97.5
-98
-101
-93.3
LTE-FDD B20 (10 MHz)
-97
-98
-101
-93.3
LTE-FDD B28 (10 MHz)
-97.5
-98
-101
-94.8
LTE-TDD B38 (10 MHz)
-97
-97
-100.5
-96.3
LTE-TDD B40 (10 MHz)
-97
-97
-100.5
-96.3
LTE-TDD B41 (10 MHz)
-96.5
-96.5
-100
-94.3
