Quectel LTE-A Series User Manual

LTE-A Module Series
EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 42 / 82
“*” means under development.
3.11. UART Interfaces
The module provides two UART interfaces: the main UART interface and the debug UART interface.
Their features are shown below:
⚫ The main UART interface supports 4800 bps, 9600 bps, 19200 bps, 38400 bps, 57600 bps, 115200
bps, 230400 bps, 460800 bps and 921600 bps baud rates, and the default baud rate is 115200 bps.
This interface is used for data transmission and AT command communication.
⚫ The debug UART interface supports 115200 bps baud rate. It is used for Linux console and log
output.
The following tables show the pin definition.
Table 11: Pin Definition of the Main UART Interface
Table 12: Pin Definition of the Debug UART Interface
Pin Name
Pin No.
I/O
Description
Comment
MAIN_RI
61
DO
Main UART ring indication
1.8 V power domain
MAIN_DCD
59
DO
Main UART data carrier detect
1.8 V power domain
MAIN_CTS
56
DO
Main UART clear to send
1.8 V power domain
MAIN_RTS
57
DI
Main UART request to send
1.8 V power domain
MAIN_DTR
62
DI
Main UART data terminal ready
1.8 V power domain
MAIN_TXD
60
DO
Main UART transmit
1.8 V power domain
MAIN_RXD
58
DI
Main UART receive
1.8 V power domain
Pin Name
Pin No.
I/O
Description
Comment
DBG_TXD
137
DO
Debug UART transmit
1.8 V power domain
NOTE
