LTE-A Module Series
EG060V-EA Hardware Design
EG060V-EA_Hardware_Design 56 / 82
Below is a reference design of USB_BOOT interface.
Module
USB_BOOT
VDD_EXT
4.7 k
Test point
TVS
Close to module
Figure 30: Reference Design of USB_BOOT Interface
