ISCOM2600G (A) Series Product Description
3 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
26
ISCOM2624G-4GE-PWR-DC
Take the AC model for example. Figure 3-20 shows the rear panel of the ISCOM2624G-4GE-
PWR-DC.
Figure 3-23 Rear panel of ISCOM2624G-4GE-PWR-DC
1
Ground terminal
2
Power switch
3
Power interface
ISCOM2624G-4GE-RPS-AC
Take the AC model for example. Figure 3-24 shows the rear panel of the ISCOM2624G-4GE-
RPS-AC.
Figure 3-24 Rear panel of ISCOM2624G-4GE-RPS-AC
1
RPS power interface
ISCOM2624G-4C-AC/DC
Figure 3-25 shows the rear panel of the ISCOM2624G-4C-AC/DC.
Figure 3-25 Rear panel of ISCOM2624G-4C-AC/DC
ISCOM2648G-4GE-AC
Figure 3-25 shows the rear panel of the ISCOM2648G-4GE-AC.
