ISCOM2600G (A) Series Product Description
3 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
39
LED
Status
Description
LNK/ACT
9–10
Green
Combo interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
PWR
Green
Power working status LED

Green: the power supply is normal.

Off: the power supply is off, the power module fails, or the
power supply is configured as a single power supply and not
installed.
SNMP
Green
SNMP interface working status LED

Green: the SNMP interface is properly connected.

Blinking green: the SNMP interface is receiving or sending
data.

Off: the SNMP interface is disconnected or improperly
connected.
SYS
Green
System working LED

Green: the system is working improperly.

Blinking green (every 1s): the system has loaded the
configuration file or the device is configured.

Off: the system is working improperly.
3.4.2 ISCOM2608G-2GE-PWR
Table 3-15 lists LEDs on the ISCOM2608G-2GE-PWR.
Table 3-15 LEDs on ISCOM2608G-2GE-PWR
LED
Status
Description
LNK/ACT
1–8
Green
Ethernet interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
–
Port 1–Port 8
PoE
Yellow
PoE working status LED

Yellow: the interface is supplying power to the remote
device.

Off: the interface is not supplying power to the remote
device.
LNK/ACT
9–10
Green
Combo interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
PWR
Green
Power working status LED

Green: the power supply is normal.

Off: the power module is not powered on or the power
module fails.
