ISCOM2600G (A) Series Product Description
3 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
42
Table 3-18 LEDs on the ISCOM2624G-4GE-RPS
LED
Status
Description
LNK/ACT
Port1–Port24
Green
Ethernet interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
LNK/ACT
Port25–Port28
Green
Combo interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
PWR
Green
Power working status LED

Green: the power supply is normal.

Off: the power supply is off or is improperly installed.
SNMP
Green
SNMP interface working status LED

Green: the SNMP interface is properly connected.

Blinking green: the SNMP interface is receiving or
sending data.

Off: the SNMP interface is disconnected or improperly
connected.
SYS
Green
System working LED

Green: the system is working improperly.

Blinking green (every 1s): the system has loaded the
configuration file or the device is configured.

Off: the system is working improperly.
RPS
Green
RPS power LED

Green: the RPS is supplying power.

Off: the RPS is not supplying power.
3.4.6 ISCOM2624G-4C
Table 3-19 lists LEDs on the ISCOM2624G-4C.
Table 3-19 LEDs on ISCOM2624G-4C
LED
Status
Description
LNK/ACT
Port1–Port24
Green
Ethernet interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
LNK/ACT
Port25–
Port28
Green
10 Gbit/s SFP+ interface working status LED

Green: the interface is properly connected.

Blinking green: the interface is receiving or sending data.

Off: the interface is disconnected or improperly connected.
