ISCOM2600G (A) Series Product Description
6 Appendix
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
73
Figure 6-9 European AC power cable
The AC power cable which meets American standard is composed of the American 3-pin plug
and C13 connector, as shown in Figure 6-10.
Figure 6-10 American AC power cable
Technical specifications
Table 6-8 lists technical specifications of the European AC power cable.
Table 6-8 Technical specifications of European AC power cable
Parameter
Description
Name
POL-AC-European-3-pin/C13 connector-0.75mm
2
-1.5m/RoHS
Color
Outer
Black (PVC insulation layer)
Inner
Blue (N), brown (L), and yellow/green stripe (E)
Connector 1
IEC60320-C13 connector
Connector 2
European 3-pin plug
Inner conductor cross-
sectional area
3×0.75 mm
2
Length
1.5 m
Table 6-9 lists technical specifications of the American AC power cable.
Table 6-9 Technical specifications of American AC power cable
Parameter
Description
Name
American 3-pin-10A/250V-1.5m/RoHS
Color
Outer
Black (PVC insulation layer)
Inner
White (N), black (L), and green (E)
Connector 1
IEC60320-C13 connector
Connector 2
American 3-pin plug NEMA5-15
