Raisecom
ISCOM2600G (A) Series Product Description
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
Figure 4-13 Connecting DC power cable
Step 4 Connect the other end of the DC power cable to the power sourcing equipment in the
equipment room.
Connecting RJ45 Console cable
Install the RJ45 Console cable as below:
Step 1 Insert the RJ45 connector of the RJ45 Console cable into the Console interface on the
ISCOM2600G series switch.
Step 2 Insert the other end of the RJ45 Console cable into the RS-232 serial interface on a PC (or
maintenance terminal), as shown in Figure 4-14.
Figure 4-14 Connecting RJ45 Console cable
4.2 Installing software
The ISCOM2600G series switch is installed with all necessary software before delivery so
that it can be powered on immediately for use after hardware installation is complete.
You can upgrade software of the ISCOM2600G series switch. For details, see ISCOM2600G
(A) Series Configuration Guide.
For details about installation and operations about the NView NNM network management
software, see the related NView NNM manual.
