Raisecom ISCOM2600G (A) Series User Manual

Raisecom
ISCOM2600G (A) Series Product Description
3 System structure
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
29
1
Ground terminal
2
Power interface
ISCOM2648G-4C-DC/D
Figure 3-32 shows the rear panel of the ISCOM2648G-4C-DC/D.
Figure 3-32 Rear panel of the ISCOM2648G-4C-DC/D
1
Ground terminal
2
Power interface
ISCOM2648G-4C-AC_DC
Figure 3-33 shows the rear panel of the ISCOM2648G-4C-AC_DC.
Figure 3-33 Rear panel of the ISCOM2648G-4C-AC_DC
1
Ground terminal
2
Power interface
3.2 Interfaces
The ISCOM2600G series switch provides external interfaces, such as service interfaces,
management interfaces, and power interfaces.
3.2.1 Service interfaces
Table 3-1 lists service interfaces on the ISCOM2600G series switch.
