ISCOM5508-GP (A) Hardware Description
2 1BComponents
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
9
Table 2-3 Interfaces on the GPSC card
Interface Type Usage Description
CONSOLE RJ45
Local
management
interface
RS-232 serial interface
SNMP RJ45
Remote network
management
interface
10/100BASE-T self-adaptive
electrical interface
GE 1/2 RJ45
Ethernet service
interface
10/100/1000BASE-T self-adaptive
electrical interface
GE 3/4 SFP
1000 Mbit/s
Ethernet service
interface
Available optical module type:
1000BASE-X
10GE 5/6 SFP+
10 Gbit/s
Ethernet service
interface
Available optical module type:
10GBASE-LX/SX
PON 1/2/3/4 PON SFP
GPON service
interface
Available optical module type: Class
B+ or Class C+
Table 2-4 lists parameters of the Console interface.
Table 2-4 Parameters of the Console interface
Parameter Description
Connector RJ45
Working mode Duplex UART
Electrical features RS-232
Baud rate 9600 Baud
Cable specifications 4-core shielded cable
Table 2-5 lists parameters of the SNMP interface.
Table 2-5 Parameters of the SNMP interface
Parameter Description
Connector RJ45
Interface rate 10/100BASE-T self-adaption
Wiring
Support straight-through and crossover cable self-adaption in host
mode
Compliant standard IEEE 802.3
