ISCOM5508-GP (A) Hardware Description
4 3BPluggable optical modules
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
38
Figure 4-2 Label of the 1000 Mbit/s SFP optical module
Table 4-1 describes the model of the 1000 Mbit/s SFP optical module.
Table 4-1 Model of the 1000 Mbit/s SFP optical module
Field Description
USFP Internal identifier, indicating it is a universal SFP
Gb Transmission rate: 1.25 Gbit/s
S1
Transmission distance:

M: 0.55 km

S1: 15 km

S2: 40 km

S3:80 km
D Support DDM.
01 Internal identifier, different values of which indicate the same function
R Comply with RoHS.
1310nm Tx wavelength: 1310 nm
SM Single-mode fiber
DDM Support link detection.
21CFR (J) Comply with U.S. DHHS 21CFR (J).
Class1 Comply with class 1 laser safety.
4.1.3 Technical specifications
Table 4-2 lists technical specifications of the 1000BASE-X SFP optical interface.
Table 4-2 Technical specifications of the 1000BASE-X SFP optical interface
Item Description
Connector LC/PC
Optical interface properties Depend on the SFP optical module.
Working mode Full duplex
Compliant standard IEEE 802.3
Supported network protocol IP
