ISCOM5508-GP (A) Hardware Description
2 1BComponents
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
21
Item Description
Voltage range -38 to -72 VDC
Output power 100 W
2.8 Fan module (FANS306)
2.8.1 Introduction
The FANS306 module is the fan module of the ISCOM5508-GP. It supports the following
features:

Support fan monitoring. The system monitors the working status of the fan and an alarm
is generated when the fan fails.

Support adjusting the rotational speed of the fan manually or automatically.

Support hot swapping.
2.8.2 Panel and slots
The FANS306 module can be inserted into slot 6 of the ISCOM5508-GP.
Figure 2-14 shows the panel of the FANS306 module.
Figure 2-14 Panel of the FANS306 module
2.8.3 LEDs
There are 2 LEDs on the FANS306 module.
Table 2-25 lists LEDs on the FANS306 module.
