ISCOM5508-GP (A) Hardware Description
3 2BFiber and cables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
35
3.6.3 Technical specifications
Table 3-13 lists technical specifications of the ground cable.
Table 3-13 Technical specifications of the ground cable
Item Description
Model PIL-ground cable-Φ4-D/RoHS
Standard Comply with the UL standard and meet RoHS requirements.
Conducting wire
Yellow/Green multi-strand copper-core conducting wire 16 AWG
(1.25 mm
2
)
Electronic wire UL1007 or UL1015 is used.
Stripped end 10 mm long and plated with tin
Insulating sheath
3.5/1.75 black heat-shrink tubing, which is a 20 mm plastic tube
and shrinks when heated
Welding technology
The conducting wire and OT terminals adopt solderless pressed
connection.
Error in length of
conducting wire
±5 mm
The letter D in the model indicates the length, which is customized. For example, if
the customer requires 2-meter cables, they are named PIL-ground cable-Φ4-
2m/RoHS.
Table 3-14 lists technical specifications of the OT terminal.
Table 3-14 Technical specifications of the OT terminal
Item Description
Model Protective grounding round pressed terminal (M4)
Standard JB2436-78
Specifications

4.3 soldering terminal

Inner diameter of soldering lug: 4 mm

Outer diameter of soldering lug: ≤ 8 mm

Inner diameter of sheath: 2.1 mm

Thickness of soldering lug: ≥ 0.6 mm
Section area of
conducting wire
17–15 AWG (1.2–1.5 mm
2
)
