ISCOM5508-GP (A) Hardware Description
3 2BFiber and cables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
24
Usage
Local
connector
Remote
connector
Type Standard
Connect the ISCOM5508-
GP to the ODF through the
PON interface.
SC/PC LC/PC 2 mm single-mode fiber
SC/PC FC/PC 2 mm single-mode fiber
SC/PC SC/PC 2 mm single-mode fiber

Choose the connector type and jumper cable length reasonably based on the on-
site requirements.

The supported connector of the optical interface depends on the optical module.

Choose a connector suitable for the optical interface. Otherwise, it may increase
additional loss of fiber links, reduce transmission quality of services, or even
damage the connector and optical interface.
3.1.2 Connector
Fiber connectors are different in shape, ferrule end-face, and pigtail sheath color, as shown in
Table 3-2.
Table 3-2 Fiber connectors
Connector Description Pigtail sheath color
LC/PC
Clamping square fiber connector/Micro-convex
grinding-and-polishing ferrule end-face
Blue
SC/PC
Square fiber connector/Micro-convex grinding-
and-polishing ferrule end-face
Blue
FC/PC
Round screw-thread connector/Micro-convex
grinding-and-polishing ferrule end-face
Blue
SC/APC
Square fiber connector/8 degree micro-convex
grinding-and-polishing ferrule end-face
Green
LC/UPC
Clamping square fiber connector/Curved
grinding-and-polishing ferrule end-face
Blue
LC/APC
Clamping square fiber connector/8 degree
micro-convex grinding-and-polishing ferrule
end-face
Green
LC/PC fiber connector
Figure 3-1 shows the appearance of the LC/PC fiber connector.
