ISCOM5508-GP (A) Hardware Description
4 3BPluggable optical modules
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
40
Table 4-4 Technical specifications of the SFP+ optical interface
Item Description
Connector LC/PC
Optical interface properties Depend on the SFP+ optical module.
Encoding type 64B/66B
Transmission rate 10 Gbit/s
Working mode Full duplex
Table 4-5 lists technical specifications of the SFP+ optical module.
Table 4-5 Technical specifications of the SFP+ optical module
Model
Tx
wavelength
(nm)
Laser type
Rx
laser
Tx
optical
power
(dBm)
Min.
overload
point
(dBm)
Extinction
ratio (dB)
Rx
sensitivity
(dBm)
Transmiss
ion
distance
(km)
USFP+-192/M 850 (VCSEL) PIN -8.2 to 1 1 4.5 -11.1 0.3
USFP+-192/S1 1310 (DFB) PIN -8.2 to 1 1 4.5 -14.4 10
4.3 PON SFP optical module
4.3.1 Functions and appearance
The PON SFP optical module can be applied to the PON system. It is integrated with sending
and receiving features.
Figure 4-4 shows the appearance of the PON SFP optical module.
Figure 4-4 PON SFP optical module
4.3.2 Standard
The GPON interface on the ISCOM5508-GP supports the optical module compliant with the
Class B+ and Class C+ standard.
