ISCOM5508-GP (A) Hardware Description
3 2BFiber and cables
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
23
3 Fiber and cables
This chapter describes fiber and cables of the ISCOM5508-GP, including the following
sections:

Fiber

Ethernet cable

Configuration cable

DC power cable

AC power cable

Ground cable
3.1 Fiber
3.1.1 Introduction
The ISCOM5508-GP supports single-mode fibers and multi-mode fibers, which are different
in color. The yellow one is a single-mode fiber and the orange one is a multi-mode fiber.
The ISCOM5508-GP can be connected to the Optical Distribution Frame (ODF) or optical
interfaces of other devices through fiber.
Table 3-1 lists the type and usage of the fiber.
Table 3-1 Type and usage of the fiber
Usage
Local
connector
Remote
connector
Type Standard

Connect the ISCOM5508-
GP to the ODF through the
Ethernet optical interface.

Connect the Ethernet
optical interface on the
ISCOM5508-GP to optical
interfaces on other
devices.
LC/PC LC/PC 2 mm single-mode fiber ITU-T G.652
2 mm multi-mode fiber
LC/PC FC/PC 2 mm single-mode fiber
2 mm multi-mode fiber
LC/PC SC/PC 2 mm single-mode fiber
2 mm multi-mode fiber
