ISCOM5508-GP (A) Hardware Description
2 1BComponents
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
17
Specification
Minimum
value
Typical
value
Maximum
value
Unit Description
Storage Temperature -20 – 80
℃
–
Humidity 5 – 95 %RH –
Power consumption for 20dBm/port – – 20 W –
MTBF @+65 ℃
15 – – Years –
Dimension(W x L x H ) 129.4×243.4×19.8 mm –
Number of CATV signal inputs/outputs Input: 1 / Output: 4 –
2.6 AC power module (RPA1101-SI-220S12)
2.6.1 Introduction
The RPA1101-SI-220S12 (hereinafter referred to as RPA1101) module is an AC power
module of the ISCOM5508-GP. It supports the following features:

Wide voltage input: 100–240 VAC

Rated output voltage: 12 V; rated output current: 8.3 A

Output overvoltage and overcurrent protection

Input surge current and voltage suppression

Power status LED

Operating temperature: -10 to +70°C

Turn off the power switch or disconnect the power connection before installing or
removing the power cable.

Ensure that the label on the power cable is correct before connecting the power
cable.

Use the power cable compliant with required specifications.
2.6.2 Panel and slots
The RPA1101 power module can be only inserted into slot 4 or slot 5.
Figure 2-12 shows the panel of the RPA1101 power module.
