Raymarine CAM220IP User Manual

2.
1Documentinformation
Thisdocumentcontainsimportantinformationrelatedtotheinstallationof
yourRaymarineproduct.
Thedocumentincludesinformationtohelpyou:
•planyourinstallationandensureyouhaveallthenecessaryequipment;
•installandconnectyourproductaspartofawidersystemofconnected
marineelectronics;
•troubleshootproblemsandobtaintechnicalsupportifrequired.
ThisandotherRaymarineproductdocumentsareavailabletodownloadin
PDFformatfromwww.raymarine.com/manuals.
2.2Applicableproducts
Thisdocumentisapplicabletothefollowingproducts:
PartnumberNameDescription
E70347CAM220IP
EyeballIP
camera
2.3Documentillustrations
Y ourproductandifapplicable,itsuserinterfacemaydifferslightlyfromthat
shownintheillustrationsinthisdocument,dependingonproductvariantand
dateofmanufacture.
Allimagesareprovidedforillustrationpurposesonly.
2.4Productdocumentation
Thefollowingdocumentationisapplicabletoyourproduct:
DescriptionP
artnumber
C
AM220IPEyeballCameraInstallationinstructions
(thisdocument)
InstallationofaCAM220IPandconnectiontoawider
systemofmarineelectronics.
87268
C
AM220IPsurfacemountingtemplate
MountingdiagramformountingaCAM220IP.
87269
Lighthouse2MFDOperationInstructions
DetailstheoperationoftheCameraapplicationfor
multifunctiondisplaysrunningtheLightHouse2
software
.
81360
Lighthouse3MFDOperationInstructions
DetailstheoperationoftheCameraapplicationfor
multifunctiondisplaysrunningtheLightHouse3
software
.
81370
Lighthouse4MFDOperationInstructions
DetailstheoperationoftheCameraapplicationfor
multifunctiondisplaysrunningtheLightHouse4
software
.
81406
gSSeriesInstallationandoperationinstructions
IncludesdetailsforoperationoftheCameraapplication
onagSSeriesMFD.
81344
2.5Operationinstructions
Fordetailedoperationinstructionsforyourproduct,refertothe
documentationthataccompaniesyourdisplay.
AllproductdocumentationisavailabletodownloadfromtheRaymarine
website:www.raymarine.com/manuals.
