oEClassCurrent(mA)
Powerrange
(Watt)
Class
description
Class217to203.84Wto6.49W
L
owpower
Class326to306.49Wto12.95
W
Midpower
Class436to4412.95Wto25.5
W
Highpower
ThePSEwillalwaysallocatethemaximumpowerbasedontheclassification
ofthePD .
Caution:Serviceandmaintenance
Thisproductcontainsnouserserviceablecomponents.Please
referallmaintenanceandrepairtoauthorizedRaymarine
dealers.Unauthorizedrepairmayaffectyourwarranty.
W ateringress
Wateringressdisclaimer
Althoughthewaterproofratingcapacityofthisproductmeetsthestated
wateringressprotectionstandard(refertotheproduct’sT echnical
Specification),waterintrusionandsubsequentequipmentfailuremayoccur
iftheproductissubjectedtohigh-pressurewashing.Raymarinewillnot
warrantproductssubjectedtohigh-pressurewashing.
Disclaimer
Raymarinedoesnotwarrantthatthisproductiserror-freeorthatitis
compatiblewithproductsmanufacturedbyanypersonorentityotherthan
Raymarine.
Raymarineisnotresponsiblefordamagesorinjuriescausedbyyouruseor
inabilitytousetheproduct,bytheinteractionoftheproductwithproducts
manufacturedbyothers,orbyerrorsininformationutilizedbytheproduct
suppliedbythirdparties.
EMCinstallationguidelines
Raymarineequipmentandaccessoriesconformtotheappropriate
ElectromagneticCompatibility(EMC)regulations,tominimizeelectromagnetic
interferencebetweenequipmentandminimizetheeffectsuchinterference
couldhaveontheperformanceofyoursystem.
CorrectinstallationisrequiredtoensurethatEMCperformanceisnot
compromised.
Note:
Inareasofe
xtremeEMCinterference,someslightinterferencemaybe
noticedontheproduct.Wherethisoccurstheproductandthesourceof
theinterferenceshouldbeseparatedbyagreaterdistance.
ForoptimumEMCperformancewerecommendthatwhereverpossible:
•Raymarineequipmentandcablesconnectedtoitare:
–Atleast1m(3.3ft)fromanyequipmenttransmittingorcablescarrying
radiosignalse.g.VHFradios,cablesandantennas.InthecaseofSSB
radios,thedistanceshouldbeincreasedto2m(6.6ft).
–Morethan2m(6.6ft)fromthepathofaradarbeam.Aradarbeam
cannormallybeassumedtospread20degreesaboveandbelowthe
radiatingelement.
•Theproductissuppliedfromaseparatebatteryfromthatusedforengine
start.Thisisimportanttopreventerraticbehavioranddatalosswhichcan
occuriftheenginestartdoesnothaveaseparatebattery.
•Raymarinespecifiedcablesareused.
•Cablesarenotcutorextended,unlessdoingsoisdetailedinthe
installationmanual.
Note:
Whereconstraintsontheinstallationpreventanyoftheabove
recommendations,alwaysensurethemaximumpossibleseparation
betweendifferentitemsofelectricalequipment,toprovidethebest
conditionsforEMCperformancethroughouttheinstallation.
Suppressionferrites
•Raymarinecablesmaybepre-fittedorsuppliedwithsuppressionferrites.
TheseareimportantforcorrectEMCperformance.Ifferritesaresupplied
Importantinformation
