1.V esselpowersupplypositive(+)
2.Vesselpowersupplynegative(-)
3.In-linefuse.(Ifyourproduct’spowercabledoesnothaveanin-linefuse
thenoneshouldbefitted.)
4.Productpowercable
5.Vesselbattery
Sharingabreaker
Wheremorethan1pieceofequipmentsharesabreakeryoumustprovide
protectionfortheindividualcircuits.E.g.byconnectinganin-linefusefor
eachpowercircuit.
1
Positive(+)bar
2
Negative(-)bar
3Circuitbreaker
4Fuse
Wherepossible,connectindividualitemsofequipmenttoindividualcircuit
breakers.Wherethisisnotpossible,useindividualin-linefusestoprovide
thenecessaryprotection.
