Raymarine CAM220IP User Manual

3.
1ProductOverview
TheCAM220IPisanInfraredilluminated(I
2
)eyeballIPcamerawithboth
dayandnightvision.Inconjunctionwithacompatiblemultifunctiondisplay
(MFD),thecameraprovidesahigh-definitionimagewhichcanbeviewedor
recordedforlaterplayback.
Thecamerahasthefollowingfeatures:
•2megapix el1/2.8"SONYprogressivescanCMOSimagesensor(Exmor)
forexcellentimagequality
•3.6mmwide-anglemegapixelboardlens
•20mI
2
beamdistance
•FieldofView(Horizontal=51.0°/Vertical=93.0°±3°)
•Multi-streamingofH.264andMJPEG
•FullHD(supportsimageresolutionsupto1920x1080(1080p),at30fps)
•12Vdcpower
•Class2PoEdevice(IEEE802.3af)
ThecameracanalsobeconnectedtoaPCwhichenablesuseofthebuilt-in
webinterfacetoaccessadditionalfeatures.Theseadditionalfeaturescan
onlybeconfiguredorusedviaaconnectedPC.
Approximaterecordtimes
TheapproximaterecordtimesaredependantonIPcameraresolutionand
settings,lightingconditionsandavailablestoragespace.
ARaymarine
®
CAM220IP,settofactorydefaultsettingscanrecordatan
approximaterateof22.5MBperminute;allowingupto44minutesofrecord
timeper1GBofavailablestoragespace.
3.2Compatiblemultifunctiondisplays
ThisproductiscompatiblewiththefollowingLightHousepoweredRaymarine
multifunctiondisplays.
•Axiom,Axiom+,AxiomPro,AxiomXL.
•aSeries,cSeries,eSeries.
•gSSeries.
LighthouseMFDsoftwarerequirements
TousethisproductwithaRaymarineLightHouse
TM
MFD,ensurethatyour
MFDisrunningtherequiredversionofthesoftware.
MFDsoftwareRequiredversion
LightHouse
TM
2R12orlater
LightHouse
TM
33.0orlater
LightHouse
TM
4
4.0orlater
Note:
ThelatestMFDsoftwarecanbeobtainedbyvisitingwww.rayma-
rine.com/software
3.3Typicalsystems
Note:Theillustrationsbelowshowproductsthatcanbeconnectedina
typicalsystem.Forinformationonhowtoconnecttheproducts,refertothe
Chapter8Cablesandconnectionssection.Forinformationonavailable
cablesandaccessories,refertotheChapter15Sparesandaccessories
section.
