Raymarine CAM220IP User Manual

1
MFD(providingP oEtothecamera)
2
IPcamera
3
W aterproofRJ45ethernetcoupler(R32142)(supplied)
4
Camera ’sethernetconnection
5
Camera ’spowercable(connectionnotrequiredascamerais
beingsuppliedPoEbytheMFD.)
6
R ayNettoSea Talk
hs
adaptorcable(notsupplied)
ConnectionviaP oEinjector
ThecameracanalsobepoweredusingaPoEinjector.
1MFD
2
IPcamera
3
P
oEinjector(R32141)(notsupplied)
4
Camera
’sethernetconnection
5
R
ayNettoSeaTalk
hs
adaptorcable(notsupplied)
6
Camera
’spowercable(Connectionnotrequiredascamera
isbeingsuppliedPoEbytheinjector.)
Important:
Allconnectionsshouldbemadeinadryareaandbesuitablyinsulatedto
preventcorrosionandpossibleproductdamageduetowateringress.
Warning:PoweringPoEdevices
Thisdevicecanbepoweredoveritsethernetconnection
(PoE)ORviaitsdedicatedpowercable.
NEVERconnectthedevice’sdedicatedpowercablewhenthe
deviceisbeingsuppliedPoE.
PowerOverEthernet(PoE)
PoEisasystemwhichallowselectricalpowertobepassedfromaPSE
(PowerSourcingEquipment)devicealongtheethernetconnectiontosupply
powertoaPD(PoweredDevice).Thisallowsasinglecabletobeusedto
providebothdataconnectionandelectricalpowertocompatibledevices.
PoEClassifications
PSEdevicesdetecttheindicatedpowerrange/classificationofconnected
PDsandallocatethenecessarymaximumpowerbasedonthePDs
classification
ThePoEclassificationsareasfollows:
PoEClassCurrent(mA)
Powerrange
(Watt)
Class
description
Class00to40.44Wto12.94
W
-
Class19to120.44Wto3.84W
Verylowpower
Class217to203.84Wto6.49W
Lowpower
Cablesandconnections33
