Raymarine CAM220IP User Manual

10
.1AugmentedReality(AR)overview
ClearCruise™AugmentedRealityusesdatafromtheMFD’sChartappand
displaysthisdatainrealtimeasanoverlayintheVideoapp.
The A ugmentedRealityfeatureplaceslayersofdigitalinformationdirectly
overthetopoftheVideoapp’svideofeed.DatafromtheChartappisused
togenerateinformativetextandimages(flags)ontheVideoapp.When
calibratedcorrectly,ClearCruise™AugmentedRealityaccuratelyoverlays
automatically-updatingflagsontheVideoappsotheyoverlapreal-life
objects.
TheAugmentedRealityfeaturerequiresanAxiom,Axiom+,AxiomProor
AxiomXLMFD,anAR200sensor,andacompatiblecamera.
Note:
•TheA ugmentedRealityfeaturerequirescorrectcameracalibrationfor
accurateimageoverlay.
•TheAugmentedRealityfeatureservesasanaidtonavigationand
situationalawarenessonly,andshouldnotbesolelyreliedonforprecise
navigation.Alwaysmaintainavisualwatch.
Important:R
ear-facingcameraswithaflippedormirroredimagemaynot
placeAugmentedRealitycontentasaccuratelyasaforward-facingcamera.
10
.2Augmentedreality
CAM220IPcanbeusedwithaRaymarineAR200toenableClearCruise™
AugmentedRealityfeatures.Belowisatypicalsystemexampleshowingthe
componentsandconnectionsrequiredtoenableClearCruise™Augmented
Realityonyoursystem.
1.AR200.
2.SeaT alkng®backbone(providing12VdcpowertotheAR200).
3.CAM220IP(CAM210IPisalsocompatible).
4.AxiomLightHouse™3orLightHouse™4MFD(runningLH3version3.7or
above,orLH4version4.0orabove).
56
