IREQUIREIMMEDIATEASSISTANCE

OVER

3.Releasethe

PTTbutton.

MakingaMaydaycall

InanemergencyyoucanalsomakeaMaydaycallfollowingtheinstructionsbelow.

1.Pressthe16PLUSbutton.

2.PressandholdthePTTbutton.

3.Slowlyandclearlyspeakthedetailsofthedistress:

MAYDAY,MAYDAY,MAYDAY

Thisis—statenameofvessel3times

MAYDAY—statenameofvessel1time

Mypositionis—statelatitudeandlongitude,ortruebearinganddistancefromaknownpoint

Iam—statenatureofdistresse.g.sinking,onﬁreetc.

Ihave—statenumberofpersonsonboardandanyotherinformation—drifting,ﬂaresﬁredetc.

IREQUIREIMMEDIATEASSISTANCE

OVER

4.Releasethe

PTTbutton.

5.Ifanacknowledgementisnotreceivedthenrepeatsteps2to4above.

Cancellingadistresscallbeforetransmission

Tocanceladistresscallbeforeitistransmittedfollowthestepsbelow:

1.Releasethe

DISTRESSbuttonbeforethecountdowntimercompletes.

Whenthebuttonisreleasedyouwillbereturnedtonormaloperation.

Digitalselectivecalling(DSC)

103
