Raymarine E70492 - Product Dimensions

To Next Page

To Previous Page

Productdimensions-Wirelesshub

Thedimensionsforthewirelesshubareshownbelow.

26.7mm(1.05in)

68.04mm(2.68in)

32.16mm(1.27in)

70mm(2.76in)

109.2mm(4.30in)

121.6mm(4.79in)

6.2mm(0.24in)

87.72mm(3.45in)

29.14mm(1.15in)Min

106.95mm(4.21in)Max

244.99mm(9.65in)

TheWirelesshubincludesaﬁtted5m(16.4ft)cableforconnectiontotheRay90/Ray91Basestation.

Iftheinstallationrequiresthecabletobepassedthroughabulkheadorpanellinga20mm(0.79in)

diameterholeisrequiredtoallowtheconnectortopassthrough.
