5.14Switchingbetweenhighandlowtransmitpower

Y oucanswitchtransmitpowerusingtheHI/LObuttonontheHandset/Fistmic.

Thetransmitpowercanalsobechangedfromthe

Set-upmenu:Menu>Set-up

1.SelectPoweroutput.

SelectingthePoweroutputoptionwillswitchbetweenHigh(25watt)andLow(1watt)power

output.

Gettingstarted
