Productdimensions-Wiredhandset(Raymic)

167.34mm(6.59in)

151mm(5.94in)

66.9mm(2.63in)

70mm(2.76in)

46.7mm(1.84in)

TheWiredhandsetisﬁttedwithacoiledcable.Ensuresufﬁcientspaceisavailablebelowthedesired

mountingareatoaccommodatethecable.

Installation33
