4.13Wirelessspeaker–powerconnection

Thewirelessspeakerisanactivespeakerthatrequiresa12Vdcpowersupply.Thepowercables

shouldbeconnectedviaadistributionpanelor,ifrequireddirectlytoabattery.

RefertothePowerdistributionsectionforguidanceonconnectingtoapowersupply.

In-linefuseandthermalbreakerratings

Thewirelesshandsetchargingholsterisinternallyfused,howeveritisrecommendedthatyouﬁtan

inlinefuseonthepositivewireofyourproduct’spowercableorconnectusingathermalbreaker.

In-linefuseratingThermalbreakerrating

1.25A

1.25A(refertonotebelow)

Note:

•Thesuitablefuseratingforthethermalbreakerisdependentonthenumberofdevicesyouare

connecting.IfindoubtconsultanauthorizedRaymarine

dealer.
