4.6NMEA2000/SeaTalkng®connection

Y ourproductcantransmitdatatodevicesconnectedonSea Talkng®orNMEA2000CANbus

networks.ConnectionisestablishedusingtheDeviceNetconnectorlocatedonthebottomoftheunit.

1.UsethesuppliedDeviceNettoSea Talkng®adaptortoconnectyourproducttoyourSea Talkng®

backboneusingavailableSeaTalkng®spurcables.

2.Y oucanalsouseaDeviceNettoSeaTalkng®adaptorcable(notsupplied)toconnectyour

producttoanavailablespuronyourSeaTalkng®backbone.

3.AlternativelyyoucanconnectyourproducttoaNMEA2000backboneusingastandard

DeviceNetcable(notsupplied).

RefertoChapter14SparesandaccessoriesforalistofavailableSea Talkng®cables.

Note:

1.Theproductmustbeconnectedtoacorrectlyterminatedbackbone.

2.Y oucannotconnectyourproductdirectlytoaMFD.

3.RefertotheinstructionssuppliedwithyourSea Talkng®/NMEA2000devicefordetailson

creatingabackbone.
