9.2LoudHailer

TheRay70,Ray90andRay91canbeconnectedtoaLoudHailer.

InHailermodeanythingspokenintothehandsetisampliﬁedandbroadcastfromthehailer.The

messageisnottransmittedoverVHF/DSC.

WhenthehailerisactiveVHFcallscannotbesentorreceived.

Usingthehailer

FromtheHail/Fog/Intmenu:

Menu>Hail/Fog/Int.

1.Select

Hailer.

Hailermodeisnowactive

2.Pressandholdthe

PTTbutton.

3.Speakyourmessage.

4.Releasethe

PTTbutton.

5.Pressthe

BackbuttontoexitHailermode.

6.ThehailerlisteningvolumecanbeadjustedatanytimeinListeningmodeusingthe

Volume

Control.

7.Thehailertalkingvolumecanbeadjustedatanytime,withthe

PTTbuttonpressedusingthe

VolumeControl.

Hailer,Foghorn,andIntercom

131
