8.3 ドライブユニットの取り付け
オートパイロットシステムのドライブユニットの取り付け方法については、ドライブユニットに同梱されている専用
の取り付け説明書を参照してください。この文書は、Raymarine のウェブサイト www.raymarine.com/manuals
からもダウンロードできます。
オートパイロットドライブユニットの取扱説明書
オートパイロットドライブユニットの取扱説明書を以下に示します。ご使用のオートパイロットドライブユニットに
適した資料を選択してください：
説明 品番
Tiller Drive Installation instructions
Installation and commissioning instructions for the following Tiller Drive:
Q047
87279
ST1000+ / ST2000+ Tiller Drive Owner handbook
Installation and commissioning instructions for the following Tiller Drives:
A12004, A12005
81130
Wheel Drive Installation instructions
Installation and commissioning instructions for the following Wheel Drive:
E12093
87287
Constant Running Hydraulic Pump Installation instructions Installation
and commissioning instructions for the following Constant Running
Hydraulic Pumps:
E12171, E12172
87039
Hydraulic Linear Drive Installation instructions
Installation and commissioning instructions for the following Hydraulic
Linear Drives:
E12207, E12208, M81202, M81203
81177
Hydraulic Pump Installation instructions
Installation and commissioning instructions for the following Hydraulic
Pumps:
E12139, M81119, M81120, M81121, M81122, M81123, M81124
81178
Mechanical Linear Drive Installation instructions
Installation and commissioning instructions for the following Mechanical
Linear Drives:
M81130, M81131, M81132, M81133, M81134
81175
Rotary Drive Installation instructions
Installation and commissioning instructions for the following Rotary Drives:
M81135, M81136, M81137
81174
IO Stern Drive Installation instructions
Installation and commissioning instructions for the following Stern Drives:
M81138, E12019
81176
Universal IO Stern Drive Installation instructions
Installation and commissioning instructions for the following Stern Drive:
E12026
81180
All documents are available to download from the Raymarine website: www.raymarine.com/manuals
