4. Adjustments RICOH Ri 2000 User Manual
179
Find an appropriate adjustment value from the print result of adjustment patterns.
1. Find a pattern with a square in the lightest color and horizontal lines on both sides
aligned.
• A value on the upper of the pattern indicates an appropriate adjustment value.
• An appropriate adjustment value is “+6”.
NOTE - In some cases, an adjustment value is an in-between value of patterns.
When a square is in the lightest color, but horizontal lines on both sides are misaligned.
In the upper illustration, a square in the lightest color is for “+6”, but horizontal lines on both
sides are misaligned. In this case, check horizontal lines for one pattern above and one
pattern below of the square.
The horizontal lines for “+2” and “+6” are misaligned in the same direction, but the horizontal
lines for “+14” are misaligned in the opposite direction.
To Next Page
