Ricoh Ri 2000 User Manual

2. Printing RICOH Ri 2000 User Manual
99
2.4. Adjusting the Height of the Platen
This machine adjusts the height of the platen automatically.
The height adjustment of the platen must be performed before printing a garment.
The adjustment result will be reset 2 hours after the last print.
Once height adjustment of the platen is performed, you can print without height adjustment until the height
adjustment result is reset.
Flatten the clothes set onto the platen as much as possible.
Press [HEIGHT ADJUST].
Next step differs depending on “OPTIONAL PLATEN” setting.
For details, see page 47, "[HEIGHT SETTING]" in “Settings Tab”.

Ricoh Ri 2000 Specifications

General

Print Technology	Inkjet
Ink Type	Pigment Ink
Connectivity	USB, Ethernet
Operating System Compatibility	Windows
Weight	250 lbs
Printhead	Ricoh
Print Resolution	1200 x 1200 dpi
Substrate Compatibility	Cotton, Polyester, Blends
Power Requirements	AC 100-240V, 50/60 Hz
