Ricoh SK5040 User Manual

1.Replacement and Adjustment
69
8. Above the spring, pull the tension bracket down [1] as far as it will go, and tighten the tension
screw [2]
9. Tighten all the screws ( x8).
Paddle Roller
Paddle Roller Cleaning
Preparation
 Open the front door
 Remove the roll-away cart (Roll-Away Cart D456)
