1.Replacement and Adjustment
78
Fans
Cooling Fan Motor for Paper Transport Motors
Preparation
 Remove the rear lower cover and rear upper cover. (Rear Lower Cover, Rear Upper Cover)
1. Remove the cooling fan motor with the bracket ( x1, x1).
2. Remove the cooling fan motor ( x2, x1)
Cooling Fan for Entrance Motor
1. Remove the rear lower cover and rear upper cover. (Rear Lower Cover, Rear Upper Cover)
