1.Replacement and Adjustment
73
Switches, Solenoid
Door Switches
Front Door Switch
Preparation
Remove these parts:
 Top front cover (Proof Tray, Top Front Cover, Top Center Cover, Top Rear Cover)
 Top center cover (Proof Tray, Top Front Cover, Top Center Cover, Top Rear Cover)
1. Loosen the connectors [A] ( x2)
2. Depress the releases [B] on both sides of the switch and remove the switch ( x2).
