RIGOL Chapter 6 Operations and Measurements
6-28 MSO8000 User Guide
indicate the times of data acquisition or acquisition probability.
⚫ Press More → Reset ColorGrade to clear the color grade display and display
the color grade again.
Math Operation Label
Press Label to enter the label setting menu.
⚫ Press Display continuously to enable or disable the label display of the
waveform. If it is enabled, the label will be displayed at the left side of the
waveform.
⚫ Press Library to select the preset waveform label, including ADD, SUB, MUL,
DIV, FFT, AND, OR, XOR, NOT, Intg, Diff, Sqrt, Lg, Ln, Exp, Abs, LPas, HPas, BPas,
BStop, and AX+B.
⚫ Press Label, and the label editing interface is automatically displayed. You can
input the label manually. For details, refer to descriptions in "Channel Label".
