Chapter 1 Quick Start RIGOL

MSO8000 User Guide 1-21

Quick Key (Shortcut Key)

Press this key to perform the quick operation, including screenshot,

waveform saving, setup saving, all measurement, and statistics reset.

Press Utility → More → Quick settings to set the quick shortcut

keys.
