Rigol MSO8000 Series User Manual

Chapter 19 Store and Load RIGOL
MSO8000 User Guide 19-7
Press Load Setup to load the setups from the internal memory or the external USB
disk. The default file type is "*.stp", and no other options are available. Load the file
from the memory, then press Load to load the selected file.
Internal Storage and Load
The internal memory supports the storage and load of the image file, waveform file,
setup file, reference waveform file, and pass/fail test mask file.
1. Save the Specified Oscilloscope Setups to the Internal Memory (Take
Save Setup as an Example)
1) Connect a signal to the oscilloscope and obtain the stable display of
waveforms.
2) Press Storage → Save Setup to enter the setup storage interface. The
disk management interface is displayed automatically. By default, "Local
Disk(C)" is selected.
3) Rotate the multifunction knob or enable the touch screen to open the
internal memory storage interface.
4) Rotate the multifunction knob to select the desired storage location,
and then press down the knob to open it. You can also enable the touch
screen to select the storage location. Rotate the multifunction knob to
select , then press down the knob or enable the touch screen to tap
to go to the previous location. Besides, you can also press NewFolder
to create a new storage folder. For details, refer to descriptions in "To
Create a Folder".
5) Press File Name to name the setup file for storage. For details, refer to
descriptions in "To Create a Folder". Press Storage → More → Auto
Name to select "ON", then the filename is generated automatically. If the
filename that you input is the same as the existing filename, a prompt
message will be displayed, reminding you that the existing file will be
overwritten and asking you whether to continue or not.
6) Press Save to save the set setup file to the selected folder in "*stp" format.
Tip
1. After saving the reference waveform, press Ref → More → Export to enter
the disk management interface of reference waveform file storage.
2. Press Utility → PassFail to enable the pass/fail test function. Then press
Mask → Save to enter the disk management interface of pass/fail test mask
file storage.
2. Load the Setup File from the Internal Memory (Take Load Setup as an
Example)
1) Press Storage → Load Setup to enter the setup load interface. The disk
