5-2 Install and Replace Components
Compatibility of Terminal
Components
When assembling components of a terminal or replacing the internal
compact flash in a logic module, the components must be compatible.
To verify compatibility of the internal compact flash with the logic
module, you must know what version of RSView ME is running on the
terminal.
1. Locate the green label on the back of the logic module to
determine the revision level of your terminal.
• Rev B: Contains RSView ME 3.0
• Rev C: Contains RSView ME 3.10
• Rev D: Contains RSView ME 3.20
• Rev E: Contains RSView ME 4.0
2. Determine the series of the internal compact flash and logic
module.
PanelView Plus Compatibility
The table matches the correct series of the internal compact flash card
with the correct series of the logic module for the terminals. The logic
module is available with or without memory installed.
RSView ME terminals are compatible with .mer applications that are
the same version or a previous version. For example, RSView ME 3.20
terminals can run RSView 3.0, 3.10, and 3.20 .mer applications.
Terminal
Revision
Logic Module 2711P-RPx is
compatible with:
Internal Compact Flash
2711P-RW1, 2, 3, 4
RSView ME
Version
Rev B
(1)
(1)
When upgrading RSView ME 3.0 to 3.10 or higher, the Firmware Upgrade Kit is required.
Series A: 2711P-RPx/A Series B: 2711P-RWx/B RSView ME 3.0
Rev C Series B: 2711P-RPx/B Series C: 2711P-RWx/C RSView ME 3.10
Series D: 2711P-RWx/D
Series E: 2711P-RWx/E
RSView ME 3.20
Series F: 2711P-RWx/F RSView ME 4.0
Rev D Series C: 2711P-RPx/C
Series D: 2711P-RPx/D
Series D: 2711P-RWx/D
Series E: 2711P-RWx/E
RSView ME 3.20
Series F: 2711P-RWx/F RSView ME 4.0
Rev E Series D: 2711P-RPx/D
Series E: 2711P-RPx/E
Series D: 2711P-RWx/D
(2)
Series E: 2711P-RWx/E
(2)
(2)
Recommend firmware upgrade to align firmware in the logic module and the internal compact flash.
RSView ME 3.20
Series F: 2711P-RWx/F RSView ME 4.0
700 - 1500 Terminals Only
To Next Page
