Rockwell Automation Allen-Bradley PanelView Plus Series User Manual

Publication 2711P-UM001D-EN-P - September 2005
Terminal Connections 6-5
Communication Port
Isolation
The terminals contain integral and modular (externally attached)
communication ports. These ports may contain electrical isolation
depending on the catalog number of the terminal or communication
module.
Integral Communication Port Isolation
400 and 600 Modular Communication Port Isolation
700 - 1500 Modular Communication Port Isolation
Communication Port 400 and 600 Terminal 700-1500 Terminal
RS-232 Non-isolated Isolated
USB Non-isolated Non-isolated
Ethernet Non-isolated Non-isolated
Communication Port Module Isolation
RS-232 2711P-RN22C Isolated
DH-485 2711P-RN3 Non-isolated
DH+ 2711P-RN8 Non-isolated
Remote I/O 2711P-RN1 Non-isolated
DeviceNet 2711P-RN10H Isolated
ControlNet 2711P-RN15C
Isolated
(1)
(1)
NAP port is non-isolated.
Communication Port Module Isolation
DH-485 2711P-RN6 Non-isolated
DH+ 2711P-RN6 Non-isolated
Remote I/O 2711P-RN6 Non-isolated
DeviceNet 2711P-RN10S Isolated
ControlNet 2711P-RN15S Isolated
