403
Effect Block
Preset patches and Algorithm list Effect Block MIDI Implementation Specifications Index
03 St. Dynamics Processor
Comp (Comp/Limiter)
This effect is able to use as a compressor, which
controls inconsistencies in sound levels by
suppressing high sound levels while lifting weaker
signals, or as a limiter that prevents the signal from
reaching exceedingly high levels.
1.
Threshold
Value: -60–0 dB
Sets the volume level at which the compression
begins.
2.
Ratio
Value: 1:1.5, 1:2, 1:4, 1:100
Sets the “source sound:output sound” compression
ratio.
3.
Attack
Value: 0–100
Sets the time after the sound volume is crossed the
threshold level until compression begins.
4.
Release
Value: 0–100
Sets the time for compression to stop after the sound
falls back under the threshold level.
5.
Output Level
Value:-60–+12 dB
Sets the output volume.
When used as a limiter, set the Ratio to 100:1 with a
short release time. If the volume exceeds the
threshold level, the sound is suppressed instantly
detected as the excess input.
Enhan (Enhancer)
This effect regulates the high-end overtones,
clarifying the sound and the sound contour.
1.
Sens
Value:0–100
Sets the degree to which the Enhancer is applied.
2.
Freq
Value:1.0–10.0 kHz
Sets the lower limit of the frequencies to which the
enhancement effect is added.
3.
Mix Level
Value: 0–100
Sets the level of the overtones produced by the
Enhancer that is mixed in with the source sound.
4.
Output Level
Value: 0–100
Sets the output volume.
ECS05_manual_e.book 403 ページ ２００５年１１月３０日 水曜日 午前１１時１４分
