RuggedRouter® User Guide
IPSec traffic arriving at the firewall is directed to openswan, the IPSec daemon.
Openswan then decrypts the traffic and forwards it back to shorewall on the assigned
ipsecX interface. You will also need a rule to allow traffic to enter from this interface.
For example, if openswan creates interface ipsec0 when its connections are
established, and ipsec0 is in the zone vpn, you would need the following rule.
ACCEPT vpn loc
Note that if your firewall itself is required to communicate with the VPN you will
need rules such as the following.
ACCEPT vpn fw tcp ssh
Policy Based Virtual Private Networking
Begin configuration by creating local, network and vpn zones. Identify the network
interface that carries the encrypted IPsec traffic and make this interface part of zone
“ANY” in the interfaces menu as it will be carrying both traffic for both zones.
Visit the Zone Hosts menu and, for the network interface that carries the encrypted
IPsec traffic, create a zone host with zone VPN, the correct subnet and the IPsec zone
option checked. If you plan to have VPN tunnels to multiple remote sites ensure that
a zone host entry exists for each (or collapse them into a single subnet). Create
another zone host for the same interface with a network zone, using a wider subnet
mask such as 0.0.0.0/0. It is important that the vpn zone be declared before the net
zone since the more specific vpn zone subnet must be inspected first.
Host Zone Interface Subnet IPsec Zone?
vpn w1ppp 192.168.1.0/24 Yes
net w1ppp 0.0.0.0/0 No
The IPsec protocol operates on UDP port 500 and using protocols ah (Authentication
Header) and Encapsulating Security Payload (ESP) protocols. The firewall must
accept this traffic in order to allow IPsec.
Action Source-Zone Destination-Zone Protocol Dest-Port
ACCEPT net fw ah
ACCEPT net fw esp
ACCEPT net fw udp 500
IPSec traffic arriving at the firewall is directed to openswan, the IPSec daemon.
Openswan then decrypts the traffic and forwards it back to shorewall on the same
interface that originally received it. You will also need a rule to allow traffic to enter
from this interface.
ACCEPT vpn loc
118 RuggedCom
