Testing Headlight Switch
3. Touch leads where
indicated. LED should light
(polarity of probes does not
matter).
4. Set DMM to Resistance mode
This is a latching switch.
Pressing the button alternates between open
and closed switch.
1. Disconnect Main Power from Mower.
2. DMM set to “Diode” mode.
19
