Indoor Unit(cont.)
QSlim duct
Model AM017FNLDEH/TK AM022FNLDEH/TK AM028FNLDEH/TK AM036FNLDEH/TK AM045FNLDEH/TK AM056FNLDEH/TK
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50 1/220~240/50
Mode*
1)
HP / HR HP / HR HP / HR HP / HR HP / HR HP / HR
Performance
Capacity
Cooling*
2)
kW 1.7 2.2 2.8 3.6 4.5 5.6
Btu/h 4,600 7,500 9,500 12,200 15,300 19,100
Heating*
3)
kW 1.9 2.5 3.2 4.0 5.0 6.3
Btu/h 5,200 8,500 10,900 13,600 17,000 21,400
Condensate (with High fan speed) Liters/h 0.80 1.12 1.28 2.07 2.39
Power
Input W
55 55 60 65 90 95
Running Current A 0.3 0.3 0.32 0.33 0.52 0.53
Sound Level Sound Pressure *
4)
dB(A) 37 37 37 37 40 43
Fan
Type -
Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor
Model -
YSK95-28-4-B YSK95-28-4-B YSK95-28-4-B YSK95-28-4-B YSK110-50-4SM YSK110-50-4SM
Type - Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR Non Feedback SSR
Output W *5) *5) *5) *5) *5) *5)
Airflow Rate
Cooling (High) m
3
/min 5.0 4 7.5 7.5 11.0 12.0
Heating (High) m
3
/min 5.5 8.2 9.0 9.0 14.0 15.0
External Static Pressure
Standard
(Min.~Max)
mmH2O 1(0~3) 1 (0~3) 1 (0~3) 1 (0~3) 2 (0~4) 2 (0~4)
Refrigerant
Type -
R410A R410A R410A R410A R410A R410A
Control Method - EEV EEV EEV EEV EEV EEV
Temperature Control -
Micom &
Thermistors
Micom &
Thermistors
Micom &
Thermistors
Micom &
Thermistors
Micom &
Thermistors
Micom &
Thermistors
Safety Devices - Fuse Fuse Fuse Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm
6.35 6.35 6.35 6.35 6.35 6.35
Gas (Flare) ø, mm 12.70 12.7 12.7 12.7 12.7 12.7
Drain ø, mm VP25 (OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
VP25
(OD 32,ID 25)
Weight
Net Weight kg
19.0 19.0 19.0 19.5 23.5 23.5
Shipping Weight kg 23.0 23.0 23.0 23.5 28.0 28.0
Dimensions
Net Dimensions (W x H x D) mm 700×199×600 700×199×600 700×199×600 700×199×600 900×199×600 900×199×600
Shipping Dimensions (W x H x D) mm 950x270x710 950x270x710 950x270x710 950x270x710 1150×280×710 1150×280×710
Functions
Auto Restart -
OOOOOO
Auto Swing - XXXXXX
Group/Individual Control - OOOOOO
External Contact Control - OOOOOO
Trouble Shooting by LED - XXXXXX
Standard
Accessories
Installation Manual -
OOOOOO
Operation Manual - OOOOOO
Pattern Sheet for Installation - XXXXXX
Flexible Drain Hose - OOOOOO
Filter / Safety Grille - Filter(Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable) Filter (Washable)
Drain Pump (Pumping speed, lift) - MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01 MR-BH01
Optional
Accessories
Wireless Remote Controller -
MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00 MR-DH00
Duct Receiver Kits
Receiver
- MRK-A10 MRK-A10 MRK-A10 MRK-A10 MRK-A10 MRK-A10
Receiver Wire
- MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A MRW-10A
Wired Remote
Controller
Simplified - MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N MWR-WE10N
External Contact Interface Module MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14 MIM-B14
Drain Pump MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D MDP-E075SEE3D
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
